spectrogon带通红外滤光片
021-50710257
13331917708(微信同号)
standard bandpass filters in stock, subject to prior sales (wavelength range uv, vis, nir & ir).
general specifications:
diameter: 25.4 mm 0/-0.2 mm. custom sizing
thickness: specified in the filter list below (mm), tol ±0.1 mm
blocking: avg < 0.1 % uv to block high
slope: < 5 % defined as:
%slope = | λ(80% of tpeak) - λc λc | x 100 |
spectral measurements:
spectral curve at room temperature and normal incidence angle is supplied with each filter type.
description: bp-cwl-hw in nanometers (hw 50 % tpeak
click on the description, to see spectral characteristics for the filters in stock.
description | substrate | thk | cwl | hw | transm | block high |
bp-0492-042 nm | color glass | 2.00 | 5,00 | 5,00 | 70,00 | 1200,00 |
bp-0495-057 nm | color glass | 4.00 | 10,00 | 10,00 | 60,00 | 1200,00 |
bp-0555-036 nm | color glass | 3.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0565-045 nm | color glass | 5.00 | 10,00 | 10,00 | 70,00 | 12000,00 |
bp-0567-040 nm | color glass | 3.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0575-040 nm | color glass | 3.00 | 5,00 | 10,00 | 70,00 | 1200,00 |
bp-0615-045 nm | color glass | 3.20 | 5,00 | 5,00 | 70,00 | 1200,00 |
bp-0658-040 nm | color glass | 2.00 | 5,00 | 5,00 | 70,00 | 1200,00 |
bp-0662-040 nm | color glass | 3.00 | 5,00 | 5,00 | 70,00 | 1200,00 |
bp-0667-040 nm | color glass | 3.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0669-040 nm | color glass | 3.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0675-040 nm | color glass | 3.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0685-040 nm | color glass | 2.00 | 5,00 | 5,00 | 70,00 | 1200,00 |
bp-0692-043 nm | color glass | 3.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0700-024 nm | color glass | 4.00 | 5,00 | 5,00 | 60,00 | 1200,00 |
bp-0750-040 nm | color glass | 1.80 | 7,00 | 7,00 | 70,00 | 1200,00 |
bp-0792-052 nm | glass | 3.00 | 10,00 | 10,00 | 60,00 | 1200,00 |
bp-0808-026 nm | color glass | 3.00 | 4,00 | 5,00 | 80,00 | 1200,00 |
bp-0830-040 nm | color glass | 2.00 | 6,00 | 6,00 | 70,00 | 1200,00 |
bp-0845-050 nm | color glass | 2.00 | 6,00 | 6,00 | 70,00 | 1200,00 |
bp-0890-055 nm | color glass | .50 | 10,00 | 10,00 | 70,00 | 1200,00 |
bp-0940-040 nm | bk7 | 1.00 | 10,00 | 10,00 | 70,00 | 1200,00 |
bp-0975-056 nm | glass | .50 | 10,00 | 10,00 | 70,00 | 1200,00 |
bp-1116-070 nm | glass | 2.00 | 10,00 | 10,00 | 50,00 | 3000,00 |
bp-1120-060 nm | glass | 1.80 | 10,00 | 10,00 | 50,00 | 3000,00 |
bp-1294-080 nm | glass | .80 | 20,00 | 10,00 | 60,00 | 3500,00 |
bp-1300-090 nm | glass | 1.00 | 20,00 | 10,00 | 60,00 | 3500,00 |
bp-1360-045 nm | glass | 1.00 | 10,00 | 10,00 | 70,00 | 3500,00 |
bp-1418-055 nm | cemented | 1.00 | 10,00 | 10,00 | 70,00 | 2800,00 |
bp-1535-090 nm | glass | 1.00 | 10,00 | 10,00 | 70,00 | 3500,00 |
bp-1540-130 nm | glass | .50 | 10,00 | 10,00 | 80,00 | 2200,00 |
bp-1550-142 nm | glass | .50 | 20,00 | 25,00 | 70,00 | 3000,00 |
bp-1570-080 nm | glass | 1.00 | 15,00 | 15,00 | 70,00 | 3500,00 |
bp-1600-090 nm | glass | 1.00 | 15,00 | 10,00 | 60,00 | 3500,00 |
bp-1640-100 nm | cemented | 1.00 | 20,00 | 15,00 | 60,00 | 3500,00 |
bp-1675-090 nm | glass | 1.00 | 10,00 | 15,00 | 70,00 | 3500,00 |
bp-1693-082 nm | glass | 1.00 | 10,00 | 10,00 | 60,00 | 3500,00 |
bp-1695-095 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1695-097 nm | glass | 1.00 | 10,00 | 10,00 | 70,00 | 3500,00 |
bp-1705-097 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1775-100 nm | mounted | 1.00 | 20,00 | 15,00 | 60,00 | 3500,00 |
bp-1820-088 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1830-110 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1835-080 nm | cemented | 1.80 | 15,00 | 20,00 | 60,00 | 3500,00 |
bp-1850-080 nm | glass | .90 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1852-037 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1853-103 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1855-104 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1858-100 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1865-080 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1865-100 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1870-104 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1875-104 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1875-107 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1885-100 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1887-065 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1915-080 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1920-080 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1920-110 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1925-100 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1930-070 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1930-100 nm | glass | .30 | 10,00 | 10,00 | 70,00 | 3500,00 |
bp-1930-112 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1932-080 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1933-080 nm | glass | .50 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1938-105 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1939-107 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1940-105 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1940-111 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1940-118 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1945-112 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1948-112 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1950-112 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1958-080 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1958-127 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1960-110 nm | glass | .30 | 10,00 | 10,00 | 70,00 | 3500,00 |
bp-1960-120 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1965-080 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1965-105 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-1965-115 nm | glass | 1.85 | 10,00 | 5,00 | 65,35 | 30000,00 |
bp-1982-087 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-2015-110 nm | cemented | 1.00 | 15,00 | 15,00 | 60,00 | 3500,00 |
bp-2080-090 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-2090-076 nm | glass | 1.00 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-2100-075 nm | glass | 1.50 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-2100-090 nm | cemented | 1.00 | 20,00 | 15,00 | 60,00 | 3500,00 |
bp-2120-090 nm | cemented | .80 | 15,00 | 20,00 | 60,00 | 3500,00 |
bp-2120-105 nm | glass | .80 | 10,00 | 10,00 | 70,00 | 3500,00 |
bp-2140-100 nm | cemented | 1.00 | 10,00 | 10,00 | 60,00 | 30000,00 |
bp-2140-110 nm | glass | .50 | 10,00 | 20,00 | 60,00 | 3500,00 |
bp-2200-100 nm | glass | .80 | 20,00 | 20,00 | 70,00 | 3500,00 |
bp-2360-080 nm | glass | 1.00 | 10,00 | 10,00 | 60,00 | 3500,00 |
bp-2365-073 nm | glass | .80 | 40,00 | 20,00 | 70,00 | 3500,00 |
bp-3050-200 nm | quartz | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3055-155 nm | quartz | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3235-100 nm | quartz | .50 | 20,00 | 20,00 | 70,00 | 30000,00 |
bp-3275-100 nm | quartz | .50 | 30,00 | 20,00 | 70,00 | 30000,00 |
bp-3317-215 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3350-155 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3350-200 nm | sapphire | .50 | 50,00 | 50,00 | 50,00 | 30000,00 |
bp-3360-155 nm | sapphire | 1.00 | 20,00 | 20,00 | 70,00 | 6800,00 |
bp-3390-345 nm | sapphire | 1.00 | 40,00 | 40,00 | 70,00 | 30000,00 |
bp-3420-075 nm | sapphire | 1.00 | 30,00 | 15,00 | 70,00 | 30000,00 |
bp-3439-131 nm | quartz | .50 | 40,00 | 15,00 | 70,00 | 30000,00 |
bp-3439-140 nm | quartz | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3440-130 nm | quartz | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3440-140 nm | quartz | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3443-130 nm | quartz | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3465-105 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 6900,00 |
bp-3620-175 nm | sapphire | 1.00 | 20,00 | 20,00 | 60,00 | 30000,00 |
bp-3800-180 nm | sapphire | 1.00 | 40,00 | 20,00 | 60,00 | 30000,00 |
bp-3800-180 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-3887-110 nm | sapphire | .50 | 40,00 | 15,00 | 65,00 | 30000,00 |
bp-3985-115 nm | sapphire | 1.00 | 20,00 | 20,00 | 70,00 | 30000,00 |
bp-4065-160 nm | sapphire | .47 | 40,00 | 30,00 | 70,00 | 30000,00 |
bp-4190-195 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 7000,00 |
bp-4200-440 nm | silicon | .50 | 40,00 | 20,00 | 70,00 | 6700,00 |
bp-4210-090 nm | silicon | .50 | 40,00 | 20,00 | 70,00 | 10000,00 |
bp-4220-200 nm | silicon | .50 | 40,00 | 25,00 | 60,00 | 10000,00 |
bp-4240-195 nm | sapphire | .50 | 10,00 | 10,00 | 80,00 | 30000,00 |
bp-4240-200 nm | silicon | .50 | 20,00 | 20,00 | 70,00 | 10000,00 |
bp-4245-195 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4245-200 nm | sapphire | .50 | 50,00 | 30,00 | 70,00 | 30000,00 |
bp-4260-150 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4260-180 nm | sapphire | 1.00 | 60,00 | 60,00 | 70,00 | 30000,00 |
bp-4265-120 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4265-130 nm | sapphire | .50 | 30,00 | 20,00 | 75,00 | 30000,00 |
bp-4266-150 nm | silicon | 1.00 | 25,00 | 15,00 | 65,00 | 6000,00 |
bp-4300-200 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 10000,00 |
bp-4305-125 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4350-180 nm | sapphire | 1.00 | 50,00 | 35,00 | 70,00 | 30000,00 |
bp-4440-160 nm | sapphire | 1.00 | 30,00 | 20,00 | 70,00 | 30000,00 |
bp-4450-200 nm | sapphire | 1.00 | 30,00 | 20,00 | 70,00 | 30000,00 |
bp-4475-260 nm | sapphire | 1.00 | 50,00 | 30,00 | 65,00 | 30000,00 |
bp-4500-170 nm | sapphire | 1.00 | 50,00 | 20,00 | 70,00 | 30000,00 |
bp-4520-220 nm | silicon | .55 | 20,00 | 20,00 | 75,00 | 11000,00 |
bp-4550-320 nm | sapphire | 1.00 | 50,00 | 30,00 | 70,00 | 30000,00 |
bp-4560-260 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4630-180 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4640-260 nm | sapphire | 1.00 | 50,00 | 30,00 | 70,00 | 30000,00 |
bp-4665-240 nm | sapphire | 1.00 | 40,00 | 30,00 | 70,00 | 30000,00 |
bp-4672-140 nm | sapphire | 1.00 | 50,00 | 25,00 | 55,00 | 30000,00 |
bp-4685-168 nm | silicon | .50 | 40,00 | 20,00 | 70,00 | 11000,00 |
bp-4700-600 nm | silicon | 1.00 | 60,00 | 60,00 | 75,00 | 11000,00 |
bp-4720-133 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4725-133 nm | sapphire | 1.00 | 50,00 | 25,00 | 60,00 | 30000,00 |
bp-4725-155 nm | silicon | .50 | 40,00 | 20,00 | 70,00 | 8000,00 |
bp-4740-140 nm | sapphire | 1.00 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4740-140 nm | sapphire | .50 | 40,00 | 20,00 | 70,00 | 30000,00 |
bp-4775-175 nm | silicon | .50 | 40,00 | 20,00 | 70,00 | 10000,00 |
bp-5020-250 nm | silicon | .55 | 25,00 | 25,00 | 75,00 | 11000,00 |
bp-5220-255 nm | sapphire | 1.00 | 50,00 | 35,00 | 70,00 | 30000,00 |
bp-5220-265 nm | sapphire | 1.00 | 50,00 | 35,00 | 70,00 | 30000,00 |
bp-5220-300 nm | sapphire | 1.00 | 50,00 | 35,00 | 60,00 | 30000,00 |
bp-5250-270 nm | sapphire | 1.00 | 50,00 | 35,00 | 70,00 | 30000,00 |
bp-5263-200 nm | sapphire | 1.00 | 50,00 | 25,00 | 70,00 | 30000,00 |
bp-5263-210 nm | sapphire | .76 | 85,00 | 35,00 | 60,00 | 30000,00 |
bp-5275-285 nm | sapphire | 1.00 | 50,00 | 35,00 | 70,00 | 30000,00 |
bp-5290-300 nm | sapphire | 1.00 | 50,00 | 35,00 | 60,00 | 30000,00 |
bp-5300-290 nm | sapphire | 1.00 | 50,00 | 35,00 | 60,00 | 30000,00 |
bp-5320-265 nm | sapphire | 1.00 | 50,00 | 35,00 | 60,00 | 30000,00 |
bp-6080-200 nm | sapphire | .50 | 75,00 | 25,00 | 50,00 | 30000,00 |
bp-6200-1200 nm | ge | 1.00 | 150,00 | 150,00 | 60,00 | 10500,00 |
bp-6500-210 nm | ge | 1.00 | 50,00 | 30,00 | 70,00 | 10500,00 |
bp-7720-480 nm | silicon | 1.00 | 100,00 | 80,00 | 70,00 | 18000,00 |
bp-7730-250 nm | ge | 1.00 | 60,00 | 40,00 | 70,00 | 12500,00 |
bp-7770-480 nm | silicon | 1.00 | 100,00 | 80,00 | 70,00 | 18000,00 |
bp-7900-250 nm | ge | 1.00 | 60,00 | 40,00 | 60,00 | 12500,00 |
bp-8008-439 nm | ge | .50 | 80,00 | 65,00 | 80,00 | 14000,00 |
bp-8100-230 nm | ge | .50 | 40,00 | 30,00 | 70,00 | 14000,00 |
bp-8180-250 nm | ge | .50 | 50,00 | 30,00 | 70,00 | 14000,00 |
bp-8248-452 nm | ge | 1.00 | 100,00 | 100,00 | 80,00 | 13500,00 |
bp-8520-509 nm | ge | 1.00 | 80,00 | 80,00 | 80,00 | 13500,00 |
bp-8630-200 nm | ge | 1.00 | 50,00 | 35,00 | 70,00 | 14000,00 |
bp-8635-180 nm | ge | 1.00 | 50,00 | 35,00 | 70,00 | 14000,00 |
bp-8780-320 nm | ge | .50 | 50,00 | 35,00 | 70,00 | 14500,00 |
bp-8780-335 nm | ge | .50 | 50,00 | 35,00 | 70,00 | 15000,00 |
bp-8889-301 nm | ge | .50 | 50,00 | 50,00 | 70,00 | 14000,00 |
bp-8900-500 nm | ge | 1.00 | 100,00 | 100,00 | 70,00 | 14000,00 |
bp-8950-330 nm | ge | .50 | 60,00 | 40,00 | 70,00 | 14000,00 |
bp-9127-545 nm | ge | 1.00 | 80,00 | 80,00 | 70,00 | 13500,00 |
bp-9480-613 nm | ge | 1.00 | 80,00 | 100,00 | 70,00 | 16000,00 |
bp-10350-460 nm | ge | 1.00 | 160,00 | 60,00 | 70,00 | 15000,00 |
bp-10375-600 nm | ge | 1.00 | 60,00 | 50,00 | 60,00 | 13700,00 |
bp-10400-737 nm | ge | 1.00 | 100,00 | 100,00 | 70,00 | 16500,00 |
bp-10688-744 nm | ge | 1.00 | 110,00 | 110,00 | 80,00 | 16000,00 |
bp-10740-390 nm | ge | 1.00 | 80,00 | 40,00 | 70,00 | 18000,00 |
bp-12227-912 nm | ge | 1.00 | 130,00 | 130,00 | 75,00 | 17000,00 |
bp-12835-958 nm | ge | 1.00 | 140,00 | 140,00 | 75,00 | 17000,00 |
bp-12840-820 nm | ge | 1.00 | 140,00 | 140,00 | 75,00 | 17000,00 |
bp-13465-1005 nm | ge | 1.00 | 200,00 | 200,00 | 80,00 | 18000,00 |
bp-13990-1056 nm | ge | 1.00 | 140,00 | 160,00 | 70,00 | 21000,00 |
bp-14100-850 nm | ge | 1.00 | 100,00 | 100,00 | 70,00 | 16500,00 |
bp-14138-1056 nm | ge | 1.00 | 160,00 | 160,00 | 70,00 | 21000,00 |
