standard longwave-pass filters in stock, subject to prior sales (wavelength range uv, vis, nir & ir).
general specifications:
diameter: 25.4 mm 0/-0.2 mm. custom sizing
thickness: specified in the filter list below (mm), tol ±0.1 mm
blocking: average < 0,1 % below passband through uv
slope: < 5 % defined as:
%slope = | λ(80% of tpeak) - λc λc | x 100 |
spectral measurements:
spectral curve at room temperature and normal incidence angle is supplied with each filter type.
description: lp-cuton in nanometers (cuton at 5 % transmission)
click on the description, to see spectral characteristics for the filters in stock.
description | substrate | thk | cuton 5 % | transm | t range |
lp-0325 nm | glass | .50 | 10,00 | 70,00 | 2500,00 |
lp-0350 nm | glass | .50 | 10,00 | 70,00 | 2500,00 |
lp-0410 nm | glass | 1.50 | 10,00 | 70,00 | 2500,00 |
lp-0490 nm | glass | .50 | 20,00 | 70,00 | 2500,00 |
lp-0745 nm | glass | 2.50 | 50,00 | 70,00 | 2500,00 |
lp-0795 nm | color glass | 2.00 | 20,00 | 70,00 | 1200,00 |
lp-0830 nm | glass | .50 | 20,00 | 70,00 | 2500,00 |
lp-0940 nm | b270 | 1.00 | 30,00 | 70,00 | 2500,00 |
lp-1000 nm | b270 | 1.00 | 30,00 | 70,00 | 2000,00 |
lp-1100 nm | glass | 1.00 | 30,00 | 70,00 | 2500,00 |
lp-1200 nm | b270 | 1.00 | 50,00 | 70,00 | 2500,00 |
lp-1350 nm | silicon | 1.00 | 30,00 | 70,00 | 3000,00 |
lp-1400 nm | silicon | 1.00 | 50,00 | 70,00 | 2500,00 |
lp-1500 nm | silicon | 1.00 | 50,00 | 70,00 | 3500,00 |
lp-1850 nm | ge | 1.00 | 50,00 | 70,00 | 3500,00 |
lp-1900 nm | ge | 1.00 | 50,00 | 70,00 | 4000,00 |
lp-2000 nm | ge | 1.00 | 50,00 | 70,00 | 4000,00 |
lp-2070 nm | glass | .80 | 50,00 | 60,00 | 2900,00 |
lp-2440 nm | ge | 1.00 | 30,00 | 60,00 | 3200,00 |
lp-2500 nm | ge | 1.00 | 100,00 | 70,00 | 12000,00 |
lp-2505 nm | ge | 1.00 | 100,00 | 70,00 | 5000,00 |
lp-2850 nm | silicon | .50 | 70,00 | 70,00 | 5000,00 |
lp-3000 nm | ge | 1.00 | 50,00 | 70,00 | 6000,00 |
lp-3300 nm | ge | .50 | 100,00 | 80,00 | 6200,00 |
lp-3500 nm | silicon | .50 | 100,00 | 70,00 | 4500,00 |
lp-3750 nm | ge | 1.00 | 100,00 | 70,00 | 5000,00 |
lp-4080 nm | ge | 1.00 | 100,00 | 70,00 | 5000,00 |
lp-4500 nm | ge | 1.00 | 100,00 | 70,00 | 6000,00 |
lp-4700 nm | sapphire | .47 | 100,00 | 70,00 | 5000,00 |
lp-4860 nm | ge | 1.00 | 100,00 | 70,00 | 10000,00 |
lp-5000 nm | ge | 1.00 | 100,00 | 70,00 | 10000,00 |
lp-5100 nm | ge | 1.00 | 50,00 | 70,00 | 7500,00 |
lp-6210 nm | ge | 1.00 | 100,00 | 70,00 | 13000,00 |
lp-6300 nm | ge | 1.00 | 200,00 | 70,00 | 8680,00 |
lp-6360 nm | ge | 1.00 | 200,00 | 70,00 | 13000,00 |
lp-6575 nm | ge | 1.00 | 140,00 | 70,00 | 13000,00 |
lp-6630 nm | ge | 1.00 | 200,00 | 70,00 | 13000,00 |
lp-6700 nm | ge | 1.00 | 200,00 | 70,00 | 13000,00 |
lp-6715 nm | ge | 1.00 | 200,00 | 70,00 | 13000,00 |
lp-6950 nm | ge | 1.00 | 100,00 | 70,00 | 13000,00 |
lp-7400 nm | ge | 1.00 | 200,00 | 70,00 | 13000,00 |
lp-7450 nm | ge | .50 | 150,00 | 75,00 | 12000,00 |
lp-7600 nm | ge | .50 | 200,00 | 70,00 | 12500,00 |
lp-7650 nm | silicon | 1.00 | 150,00 | 70,00 | 11000,00 |
lp-8335 nm | ge | .50 | 200,00 | 75,00 | 12500,00 |
lp-8450 nm | ge | .50 | 100,00 | 70,00 | 13000,00 |
lp-8550 nm | ge | .50 | 200,00 | 70,00 | 16000,00 |
lp-8650 nm | ge | .50 | 200,00 | 75,00 | 13000,00 |
lp-9000 nm | ge | 1.00 | 250,00 | 70,00 | 13000,00 |
lp-9000 nm | ge | .50 | 200,00 | 70,00 | 13000,00 |
lp-9650 nm | ge | .50 | 200,00 | 70,00 | 13000,00 |
lp-9700 nm | ge | .50 | 200,00 | 70,00 | 13000,00 |
lp-9800 nm | ge | .50 | 200,00 | 70,00 | 13000,00 |
lp-10000 nm | ge | .50 | 250,00 | 70,00 | 18000,00 |
lp-10150 nm | ge | 1.00 | 250,00 | 70,00 | 17000,00 |
lp-6700c nm | ge | 1.00 | 200,00 | 70,00 | 13000,00 |
