主要功能介绍：
uv shortpass filters ▪high transmission and high rejection for complete isolation ▪sharp cut-off wavelength ▪will not autofluorescence ▪excellent thermal resistance specifications material fused silica dimension tolerance -0.02/-0.2
021-50710257
13331917708(微信同号)
uv shortpass filters:
▪ high transmission and high rejection for complete isolation
▪ sharp cut-off wavelength
▪ will not autofluorescence
▪ excellent thermal resistance
specifications:
material | fused silica |
dimension tolerance | -0.02/-0.2mm (25mm dia.) |
thickness | 1mm 0.1/-0.1mm |
clear aperture | 23mm dia. (25mm dia.) |
transmission | >/=85% average |
blocking | |
cut-off tolerance | 5/-5nm |
angle of incidence | 0 degrees |
cut-off wavelength | transmission band | rejection band | item# | |
25mm dia. | 50 x 50mm | |||
265nm | 235-254nm | 283-312nm | xus0265 | zus0265 |
300nm | 240-290nm | 322-352nm | xus0300 | zus0300 |
325nm | 240-315nm | 350-380nm | xus0325 | zus0325 |
350nm | 240-340nm | 376-407nm | xus0350 | zus0350 |
385nm | 240-375nm | 416-448nm | xus0385 | zus0385 |
400nm | 250-390nm | 431-465nm | xus0400 | zus0400 |
