主要功能介绍：
uv longpass filters ▪high transmission and high rejection for complete isolation ▪sharp cut-on wavelength ▪will not autofluorescence ▪excellent thermal resistance specifications: material fused silica dimension tolerance -0.02/-0.2m
021-50710257
13331917708(微信同号)
uv longpass filters:
▪ high transmission and high rejection for complete isolation
▪ sharp cut-on wavelength
▪ will not autofluorescence
▪ excellent thermal resistance
specifications:
material | fused silica |
dimension tolerance | -0.02/-0.2mm (25mm dia.) |
thickness | 1mm 0.1/-0.1mm |
clear aperture | 23mm dia. (25mm dia.) |
transmission | >/=90% average |
blocking | |
cut-off tolerance | 5/-5nm |
angle of incidence | 0 degrees |
cut-on wavelength | transmission band | rejection band | item# | |
25mm dia. | 50 x 50mm | |||
250nm | 260-800nm | 210-233nm | xul0250 | zul0250 |
275nm | 285-800nm | 232-257nm | xul0275 | zul0275 |
300nm | 310-800nm | 200-280nm | xul0300 | zul0300 |
325nm | 340-800nm | 273-304nm | xul0325 | zul0325 |
350nm | 360-800nm | 200-331nm | xul0350 | zul0350 |
385nm | 400-800nm | 200-363nm | xul0385 | zul0385 |
400nm | 410-800nm | 200-383nm | xul0400 | zul0400 |
