high transmission uv bandpass filters:
▪ high transmission and high rejection in uv wavelengths
▪ 10nm fwhm
▪ will not autofluorescence
▪ excellent thermal resistance
material | fused silica |
dimension tolerance | -0.02/-0.2mm (25mm dia.) |
thickness | 5.50mm 0.5/-0.5mm |
clear aperture | 22mm dia. (25mm dia.) |
blocking | |
cwl tolerance | 2/-2nm |
fwhm tolerance | 2/-2nm |
angle of incidence | 0 degrees |
center wavelength | full width-half maximum | peak transmittance | rejection band | item# |
25mm dia. | ||||
254nm | 10nm | 60% | 200-450nm | xhqa254 |
260nm | 10nm | 60% | 200-450nm | xhqa260 |
270nm | 10nm | 60% | 200-450nm | xhqa270 |
280nm | 10nm | 60% | 200-450nm | xhqa280 |
290nm | 10nm | 60% | 200-450nm | xhqa290 |
300nm | 10nm | 60% | 200-520nm | xhqa300 |
310nm | 10nm | 60% | 200-520nm | xhqa310 |
313nm | 10nm | 60% | 200-520nm | xhqa313 |
320nm | 10nm | 65% | 200-520nm | xhqa320 |
330nm | 10nm | 65% | 200-520nm | xhqa330 |
334nm | 10nm | 65% | 200-520nm | xhqa334 |
340nm | 10nm | 65% | 200-520nm | xhqa340 |
350nm | 10nm | 65% | 200-520nm | xhqa350 |
360nm | 10nm | 70% | 200-520nm | xhqa360 |
365nm | 10nm | 70% | 200-520nm | xhqa365 |
370nm | 10nm | 70% | 200-520nm | xhqa370 |
380nm | 10nm | 70% | 200-520nm | xhqa380 |
390nm | 10nm | 70% | 200-520nm | xhqa390 |
