主要功能介绍：
uv bandpass filters ▪wide range blocking ▪10nm fwhm material fused silica and color glass substrates mounted in aluminum ring dimension tolerance -0.02/-0.2mm (25mm dia.) 0.5/-0.5mm (50x50mm) thickness 6.5mm (254-390nm); 6.0mm (400nm)
021-50710257
13331917708(微信同号)
uv bandpass filters:
▪ wide range blocking
▪ 10nm fwhm
material | fused silica and color glass substrates mounted in aluminum ring |
dimension tolerance | -0.02/-0.2mm (25mm dia.) |
thickness | 6.5mm (254-390nm); 6.0mm (400nm) |
clear aperture | 22mm dia. (25mm dia.) |
blocking | |
cwl tolerance | 2/-2nm |
fwhm tolerance | 2/-2nm |
angle of incidence | 0 degrees |
center wavelength | full width-half maximum | peak transmittance | rejection band | item# | |
25mm dia. | 50 x 50mm | ||||
254nm | 10nm | 20% | 200-1200nm | xbpa254 | zbpa254 |
260nm | 10nm | 20% | 200-1200nm | xbpa260 | zbpa260 |
270nm | 10nm | 20% | 200-1200nm | xbpa270 | zbpa270 |
280nm | 10nm | 20% | 200-1200nm | xbpa280 | zbpa280 |
290nm | 10nm | 20% | 200-1200nm | xbpa290 | zbpa290 |
300nm | 10nm | 30% | 200-1200nm | xbpa300 | zbpa300 |
310nm | 10nm | 35% | 200-1200nm | xbpa310 | zbpa310 |
320nm | 10nm | 45% | 200-1200nm | xbpa320 | zbpa320 |
330nm | 10nm | 45% | 200-1200nm | xbpa330 | zbpa330 |
340nm | 10nm | 45% | 200-1200nm | xbpa340 | zbpa340 |
350nm | 10nm | 45% | 200-1200nm | xbpa350 | zbpa350 |
360nm | 10nm | 40% | 200-1200nm | xbpa360 | zbpa360 |
365nm | 10nm | 40% | 200-1200nm | xbpa365 | zbpa365 |
370nm | 10nm | 40% | 200-1200nm | xbpa370 | zbpa370 |
380nm | 10nm | 45% | 200-1200nm | xbpa380 | zbpa380 |
390nm | 10nm | 45% | 200-1200nm | xbpa390 | zbpa390 |
