窄带滤光片900nm以上
主要功能介绍：
我们的**表面硬涂层窄带滤光片采用磁控溅射，硬质氧化物涂层沉积在硼硅酸盐玻璃上，不使用任何吸收滤光镜，使其适用于高温应用。它们提供从高峰值传输到od4阻塞的陡峭过渡。
021-50710257
13331917708(微信同号)
详细信息
我们的**表面硬涂层窄带滤光片采用磁控溅射，硬质氧化物涂层沉积在硼硅酸盐玻璃上，不使用任何吸收滤光镜，使其适用于高温应用。它们提供从高峰值传输到od4阻塞的陡峭过渡。可提供334nm至1550nm的波长，包括所有主要激光线和原子吸收线。所有过滤器均安装在黑色阳极氧化铝环中，以提供保护和识别。
general specifications
| thickness: | 5.0 ±0.1mm |
| size tolerance: | 0.0 / -0.1mm |
| minimum clear aperture: | 21mm dia. |
| substrate material: | borosilicate glass |
| flatness: | 3-5 waves |
| surface quality: | 60-40 per mil-c-48497a |
| humidity and abrasion: | per mil-c-67** |
| durability: | per mil-c-48497a |
| operating temperature: | -50°c to 200°c |
| mechanical: | mounted in black anodized aluminum ring |
| 900nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 900hc25-25 |
| center wavelength | 900 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 905nm cwl, 10.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 905hc10-25 |
| center wavelength | 905 2/-2 nm |
| bandwidth | 10.0 2/-2 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1200nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 940nm cwl, 10.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 940hc10-25 |
| center wavelength | 940 2/-2 nm |
| bandwidth | 10.0 2/-2 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1200nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 950nm cwl, 10.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 950hc10-25 |
| center wavelength | 950 2/-2 nm |
| bandwidth | 10.0 2/-2 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1200nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 950nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 950hc25-25 |
| center wavelength | 950 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 980nm cwl, 10.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 980hc10-25 |
| center wavelength | 980 2/-2 nm |
| bandwidth | 10.0 2/-2 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1200nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1000nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1000hc25-25 |
| center wavelength | 1000 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1050nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1050hc25-25 |
| center wavelength | 1050 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1064nm cwl, 10.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1064hc10-25 |
| center wavelength | 1064 2/-2 nm |
| bandwidth | 10.0 2/-2 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1200nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1100nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1100hc25-25 |
| center wavelength | 1100 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1150nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1150hc25-25 |
| center wavelength | 1150 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1200nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1200hc25-25 |
| center wavelength | 1200 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1250nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1250hc25-25 |
| center wavelength | 1250 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1300nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1300hc25-25 |
| center wavelength | 1300 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1400nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1400hc25-25 |
| center wavelength | 1400 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1500nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1500hc25-25 |
| center wavelength | 1500 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1550nm cwl, 10.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1550hc10-25 |
| center wavelength | 1550 2/-2 nm |
| bandwidth | 10.0 2/-2 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
| 1550nm cwl, 25.0nm bandwidth, 25.0 mm diameter, hard-coated narrowband filter | |
| part no. | 1550hc25-25 |
| center wavelength | 1550 2.0/-2.0 nm |
| bandwidth | 25.0 5.0/-5.0 nm |
| transmission | 90% |
| blocking | 1x10-4 avg. 200-1800nm |
| size | 25.0 0/-0.1mm |
| thickness | 5.0 0.25/-0.25 mm |
