宽带滤光片345-499nm
主要功能介绍：
我们的**表面硬涂层宽带滤波器采用磁控溅射，硬质氧化物涂层沉积在硼硅酸盐玻璃上，不使用任何吸收滤光镜，使其适用于高温应用。它们提供从高峰值传输到od4阻塞的陡峭过渡。
021-50710257
13331917708(微信同号)
详细信息
我们的**表面硬涂层宽带滤波器采用磁控溅射，硬质氧化物涂层沉积在硼硅酸盐玻璃上，不使用任何吸收滤光镜，使其适用于高温应用。它们提供从高峰值传输到od4阻塞的陡峭过渡。可在标准拉曼波长下使用：488,514,532,633,785nm，以及其他常用波长。我们提供三种标准尺寸，可根据要求提供定制尺寸和环形安装
general specifications
| thickness: | 3.1±.0.25mm |
| size tolerance: | 0.0 / -0.2mm |
| minimum clear aperture: | 95% of outside dimension |
| substrate material: | boroscilicate glass |
| flatness: | 3-5 waves |
| surface quality: | 60-40 per mil-c-48497a |
| humidity and abrasion: | per mil-c-67** |
| durability: | per mil-c-48497a |
| operating temperature: | -50°c to 200°c |
| mechanical: | unmounted |
| 345.0nm cwl, 80.0nm bandwidth, 12.5 mm diameter, hard-coated broadband filter | |
| part no. | 345hc80-12.5 |
| center wavelength | 345.0 15/-15 nm |
| bandwidth | 80.0 8.0/-8.0 nm |
| transmission | 60% |
| blocking | 1x10-4 avg. x-ray to 650nm |
| size | 12.5 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 345.0nm cwl, 80.0nm bandwidth, 25.0 mm diameter, hard-coated broadband filter | |
| part no. | 345hc80-25 |
| center wavelength | 345.0 15/-15 nm |
| bandwidth | 80.0 8.0/-8.0 nm |
| transmission | 60% |
| blocking | 1x10-4 avg. x-ray to 650nm |
| size | 25.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 345.0nm cwl, 80.0nm bandwidth, 50.0 mm diameter, hard-coated broadband filter | |
| part no. | 345hc80-50 |
| center wavelength | 345.0 15/-15 nm |
| bandwidth | 80.0 8.0/-8.0 nm |
| transmission | 60% |
| blocking | 1x10-4 avg. x-ray to 650nm |
| size | 50.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 441.6nm cwl, 150.0nm bandwidth, 12.5 mm diameter, hard-coated broadband filter | |
| part no. | 442hc150-12.5 |
| center wavelength | 441.6 30/-30 nm |
| bandwidth | 150.0 15.0/-15.0 nm |
| transmission | 80% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 12.5 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 441.6nm cwl, 150.0nm bandwidth, 25.0 mm diameter, hard-coated broadband filter | |
| part no. | 442hc150-25 |
| center wavelength | 441.6 30/-30 nm |
| bandwidth | 150.0 15.0/-15.0 nm |
| transmission | 80% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 25.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 441.6nm cwl, 150.0nm bandwidth, 50.0 mm diameter, hard-coated broadband filter | |
| part no. | 442hc150-50 |
| center wavelength | 441.6 30/-30 nm |
| bandwidth | 150.0 15.0/-15.0 nm |
| transmission | 80% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 50.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 470.0nm cwl, 100.0nm bandwidth, 12.5 mm diameter, hard-coated broadband filter | |
| part no. | 470hc100-12.5 |
| center wavelength | 470.0 20/-20 nm |
| bandwidth | 100.0 10.0/-10.0 nm |
| transmission | 85-92% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 12.5 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 470.0nm cwl, 100.0nm bandwidth, 25.0 mm diameter, hard-coated broadband filter | |
| part no. | 470hc100-25 |
| center wavelength | 470.0 20/-20 nm |
| bandwidth | 100.0 10.0/-10.0 nm |
| transmission | 85-92% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 25.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 470.0nm cwl, 100.0nm bandwidth, 50.0 mm diameter, hard-coated broadband filter | |
| part no. | 470hc100-50 |
| center wavelength | 470.0 20/-20 nm |
| bandwidth | 100.0 10.0/-10.0 nm |
| transmission | 85-92% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 50.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 488.0nm cwl, 80.0nm bandwidth, 12.5 mm diameter, hard-coated broadband filter | |
| part no. | 488hc80-12.5 |
| center wavelength | 488.0 15/-15 nm |
| bandwidth | 80.0 8.0/-8.0 nm |
| transmission | 85-92% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 12.5 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 488.0nm cwl, 80.0nm bandwidth, 25.0 mm diameter, hard-coated broadband filter | |
| part no. | 488hc80-25 |
| center wavelength | 488.0 15/-15 nm |
| bandwidth | 80.0 8.0/-8.0 nm |
| transmission | 85-92% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 25.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
| 488.0nm cwl, 80.0nm bandwidth, 50.0 mm diameter, hard-coated broadband filter | |
| part no. | 488hc80-50 |
| center wavelength | 488.0 15/-15 nm |
| bandwidth | 80.0 8.0/-8.0 nm |
| transmission | 85-92% |
| blocking | 1x10-4 avg. x-ray to 750nm |
| size | 50.0 0.0/-0.2mm |
| thickness | 3.1 0.25/-0.25 mm |
