红外中性密度滤光片andover
红外中性密度滤光片andover

主要功能介绍：

金属涂覆的红外中性密度滤光片（ir nd滤光片）从由感兴趣的波长区域确定的基板上的金属合金涂层获得其光密度。与全电介质或吸收型不同，金属型nd滤光器采用吸收和反射的组合来降

021-50710257

13331917708(微信同号)

详细信息

金属涂覆的红外中性密度滤光片（ir nd滤光片）从由感兴趣的波长区域确定的基板上的金属合金涂层获得其光密度。与全电介质或吸收型不同，金属型nd滤光器采用吸收和反射的组合来降低光强度。

andover的ir nd滤光片具有出色的光谱中性，优于市场上的所有其他滤光片。

▪ 在宽光谱范围内提供更大线性度的衰减

▪ 提供**的耐用性

▪ 提供定制基材



general specifications:

dimensional tolerances:±0.2mm
thickness: 1.0mm
min. clear aperture: 90% of outside dimension
surface quality: 80/50 per mil-o-13830b
coating quality: 80/50 per mil-o-13830b
coating adherence: per mil-m-13508c
humidity: per mil-std-810f
substrate material: germanium
flatness: 3–5 waves per 25mm
parallelism: 10 arc minutes or better
mechanical:unmounted





红外中性密度滤光片andover(图1)



no.part no.part no.
1ir nd, 0.30 od, 12.5 mm diameter030fnir-12.5
2ir nd, 0.30 od, 25.0 mm diameter030fnir-25
3ir nd, 0.30 od, 50.0 mm diameter030fnir-50
4ir nd, 0.30 od, 25.0 mm diameter030fnir-bbar-25
5ir nd, 0.50 od, 12.5 mm diameter050fnir-12.5
6ir nd, 0.50 od, 25.0 mm diameter050fnir-25
7ir nd, 0.50 od, 50.0 mm diameter050fnir-50
8ir nd, 0.50 od, 25.0 mm diameter050fnir-bbar-25
9ir nd, 0.60 od, 12.5 mm diameter060fnir-12.5
10ir nd, 0.60 od, 25.0 mm diameter060fnir-25
11ir nd, 0.60 od, 50.0 mm diameter060fnir-50
12ir nd, 0.70 od, 12.5 mm diameter070fnir-12.5
13ir nd, 0.70 od, 25.0 mm diameter070fnir-25
14ir nd, 0.70 od, 50.0 mm diameter070fnir-50
15ir nd, 0.80 od, 12.5 mm diameter080fnir-12.5
16ir nd, 0.80 od, 25.0 mm diameter080fnir-25
17ir nd, 0.80 od, 50.0 mm diameter080fnir-50
18ir nd, 0.9 od, 12.5 mm diameter090fnir-12.5
19ir nd, 0.9 od, 25.0 mm diameter090fnir-25
20ir nd, 0.9 od, 50.0 mm diameter090fnir-50
21ir nd, 1.0 od, 12.5 mm diameter100fnir-12.5
22ir nd, 1.0 od, 25.0 mm diameter100fnir-25
23ir nd, 1.0 od, 50.0 mm diameter100fnir-50
24ir nd, 1.0 od, 25.0 mm diameter100fnir-bbar-25
25ir nd, 1.3 od, 12.5 mm diameter130fnir-12.5
26ir nd, 1.3 od, 25.0 mm diameter130fnir-25
27ir nd, 1.3 od, 50.0 mm diameter130fnir-50
28ir nd, 1.5 od, 12.5 mm diameter150fnir-12.5
29ir nd, 1.5 od, 25.0 mm diameter150fnir-25
30ir nd, 1.5 od, 50.0 mm diameter150fnir-50
31ir nd, 2.0 od, 12.5 mm diameter200fnir-12.5
32ir nd, 2.0 od, 25.0 mm diameter200fnir-25
33ir nd, 2.0 od, 50.0 mm diameter200fnir-50
34ir nd, 2.0 od, 25.0 mm diameter200fnir-bbar-25
35ir nd, 2.5 od, 12.5 mm diameter250fnir-12.5
36ir nd, 2.5 od, 25.0 mm diameter250fnir-25
37ir nd, 2.5 od, 50.0 mm diameter250fnir-50
38ir nd, 3.0 od, 12.5 mm diameter300fnir-12.5
39ir nd, 3.0 od, 25.0 mm diameter300fnir-25
40ir nd, 3.0 od, 50.0 mm diameter300fnir-50
