定制红外长通滤光片andover
主要功能介绍：
andover可以设计和制造长通滤光片，以满足您的特殊要求。该过程的每个阶段都在内部进行，包括薄膜涂层设计，机械设计，基板制造和涂层，检查和环境测试。 我们可以涂覆各种基板
021-50710257
13331917708(微信同号)
详细信息
andover可以设计和制造长通滤光片，以满足您的特殊要求。该过程的每个阶段都在内部进行，包括薄膜涂层设计，机械设计，基板制造和涂层，检查和环境测试。
我们可以涂覆各种基板材料，包括锗，蓝宝石，硅，硫化锌和硒化锌。我们也可以生产定制尺寸和形状。
| 1050-1650 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp08-25 |
| user must select wavelength within the range: | 1050-1650nm |
| transmission: | 80% min. |
| transmission range: | transmission range is from cut-on to 2500nm |
| please note: | unit price will drop significantly with increasing quantity |
| 1050-1650 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp08-50 |
| user must select wavelength within the range: | 1050-1650nm |
| transmission: | 80% min. |
| transmission range: | transmission range is from cut-on to 2500nm |
| please note: | unit price will drop significantly with increasing quantity |
| 1650-2100 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp10-25 |
| user must select wavelength within the range: | 1650-2100nm |
| transmission: | 80% min. |
| transmission range: | transmission range is from cut-on to 2 x cut-on w/l |
| please note: | unit price will drop significantly with increasing quantity |
| 1650-2100 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp10-50 |
| user must select wavelength within the range: | 1650-2100nm |
| transmission: | 80% min. |
| transmission range: | transmission range is from cut-on to 2 x cut-on w/l |
| please note: | unit price will drop significantly with increasing quantity |
| 2100-3000 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp12-25 |
| user must select wavelength within the range: | 2100-3000nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to 2 x cut-on w/l |
| please note: | unit price will drop significantly with increasing quantity |
| 2100-3000 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp12-50 |
| user must select wavelength within the range: | 2100-3000nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to 2 x cut-on w/l |
| please note: | unit price will drop significantly with increasing quantity |
| 3000-4500 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp14-25 |
| user must select wavelength within the range: | 3000-4500nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to >2 x cut-on w/l |
| please note: | unit price will drop significantly with increasing quantity |
| 3000-4500 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp14-50 |
| user must select wavelength within the range: | 3000-4500nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to >2 x cut-on w/l |
| please note: | unit price will drop significantly with increasing quantity |
| 4500-6000 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp16-25 |
| user must select wavelength within the range: | 4500-6000nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to 11000nm |
| please note: | unit price will drop significantly with increasing quantity |
| 4500-6000 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp16-50 |
| user must select wavelength within the range: | 4500-6000nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to 11000nm |
| please note: | unit price will drop significantly with increasing quantity |
| 6000-8000 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp18-25 |
| user must select wavelength within the range: | 6000-8000nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to 13000nm |
| please note: | unit price will drop significantly with increasing quantity |
| 6000-8000 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp18-50 |
| user must select wavelength within the range: | 6000-8000nm |
| transmission: | 85% min. |
| transmission range: | transmission range is from cut-on to 13000nm |
| please note: | unit price will drop significantly with increasing quantity |
| 8000-1100 5% cut-on (user-specified), 25.0 mm dia. | |
| part no. | irlwp20-25 |
| user must select wavelength within the range: | 8000-1100nm |
| transmission: | 80% min. |
| transmission range: | transmission range is from cut-on to 14000nm |
| please note: | unit price will drop significantly with increasing quantity |
| 8000-1100 5% cut-on (user-specified), 50.0 mm dia. | |
| part no. | irlwp20-50 |
| user must select wavelength within the range: | 8000-1100nm |
| transmission: | 80% min. |
| transmission range: | transmission range is from cut-on to 14000nm |
| please note: | unit price will drop significantly with increasing quantity |
