带通型有色滤光玻璃andover
主要功能介绍：
带通型滤光镜可用于增强照明系统的信噪比，传输宽带能量，同时阻挡较短和较长的波长。 与所有andover的滤镜一样，可根据要求提供定制尺寸，也可将其安装在螺纹环中（单击以获取
021-50710257
13331917708(微信同号)
详细信息
带通型滤光镜可用于增强照明系统的信噪比，传输宽带能量，同时阻挡较短和较长的波长。 与所有andover的滤镜一样，可根据要求提供定制尺寸，也可将其安装在螺纹环中（单击以获取尺寸）。
所有图表均显示标准3mm厚度下的内部透射率。 我们可以根据要求抛光***其他厚度。
我们的内部制造和抛光能力使我们能够快速提供定制零件的周转时间。
general specifications
| optical thickness: | 3mm ±0.5mm |
| mechanical thickness: | add 0.8mm for ring mount |
| size tolerance: | 0.00/-0.25mm |
| surface quality: | 80/50 per mil-m-13508 |
| max. operating temperature: | 100°c |
| transmitted wavefront (twf): | 1/4 wave per inch |
| parallelism: | 30 arc seconds or better |
| spectral data: | stated as internal transmittance |
| mechanical: | mounted, except for squares |
▪ fabricated from high-quality optical filter glass
▪ both surfaces precision polished
▪ options span ultraviolet to infrared region
| description | part no. |
| ug-1 filter glass, 165mm x 165mm x 3mm | 001fg09-165s |
| ug-1 filter glass, 25mm diameter | 001fg09-25 |
| ug-1 filter glass, 50mm diameter | 001fg09-50 |
| ug-1 filter glass, 50mm x 50mm x 3mm | 001fg09-50s |
| uv filter glass, 165mm x 165mm x 3mm | 005fg09-165s |
| uv filter glass, 25mm diameter | 005fg09-25 |
| uv filter glass, 50mm diameter | 005fg09-50 |
| uv filter glass, 50mm x 50mm x 3mm | 005fg09-50s |
| uv filter glass, 165mm x 165mm x 3mm | 011fg09-165s |
| uv filter glass, 25mm diameter | 011fg09-25 |
| uv filter glass, 50mm diameter | 011fg09-50 |
| uv filter glass, 50mm x 50mm x 3mm | 011fg09-50s |
| blue filter glass, 165mm x 165mm x 3mm (bg-23 or equivalent) | 023fg11-165s |
| blue filter glass, 25mm diameter (bg-23 or equivalent) | 023fg11-25 |
| blue filter glass, 50mm diameter (bg-23 or equivalent) | 023fg11-50 |
| blue filter glass, 50mm x 50mm x 3mm (bg-23 or equivalent) | 023fg11-50s |
| bg-25 filter glass, 165mm x 165mm x 3mm | 025fg11-165s |
| bg-25 filter glass, 25mm diameter | 025fg11-25 |
| bg-25 filter glass, 50mm diameter | 025fg11-50 |
| bg-25 filter glass, 50mm x 50mm x 3mm | 025fg11-50s |
| bg-40 filter glass, 165mm x 165mm x 3mm | 040fg11-165s |
| bg-40 filter glass, 25mm diameter | 040fg11-25 |
| bg-40 filter glass, 50mm diameter | 040fg11-50 |
| bg-40 filter glass, 50mm x 50mm x 3mm | 040fg11-50s |
| s-8612 filter glass, 165mm square | s86fg11-165s |
| s-8612 filter glass, 25mm diameter | s86fg11-25 |
| s-8612 filter glass, 50mm diameter | s86fg11-50 |
| s-8612 filter glass, 50mm square | s86fg11-50s |
