长通型有色滤光玻璃andover
主要功能介绍：
长通型滤镜对于订单分类应用很有用。 它们透射较短的波长，而透射较长的波长。 与所有andover的滤镜一样，可根据要求提供定制尺寸，也可将其安装在螺纹环中。 所有图表均显示标准
021-50710257
13331917708(微信同号)
详细信息
长通型滤镜对于订单分类应用很有用。 它们透射较短的波长，而透射较长的波长。 与所有andover的滤镜一样，可根据要求提供定制尺寸，也可将其安装在螺纹环中。
所有图表均显示标准3mm厚度下的内部透射率。 我们可以根据要求抛光至其他厚度。
我们的内部制造和抛光能力使我们能够快速提供定制零件的周转时间。
| general specifications | |
| optical thickness: | 3mm ±0.5mm |
| mechanical thickness: | add 0.8mm for ring mount |
| size tolerance: | 0.00/-0.25mm |
| surface quality: | 80/50 per mil-m-13508 |
| max. operating temperature: | 100°c |
| transmitted wavefront (twf): | 1/4 wave per inch |
| parallelism: | 30 arc seconds or better |
| spectral data: | stated as internal transmittance |
| mechanical: | mounted, except for squares |
| description | part no. |
| rg-9 filter glass, 165mm x 165mm x 3mm | 009fg07-165s |
| rg-9 filter glass, 25mm diameter | 009fg07-25 |
| rg-9 filter glass, 50mm diameter | 009fg07-50 |
| rg-9 filter glass, 50mm x 50mm x 3mm | 009fg07-50s |
| rg-1000 filter glass, 165mm x 165mm x 3mm | 100fg07-165s |
| rg-1000 filter glass, 25mm diameter | 100fg07-25 |
| rg-1000 filter glass, 50mm diameter | 100fg07-50 |
| rg-1000 filter glass, 50mm x 50mm x 3mm | 100fg07-50s |
| wg-280 filter glass, 165mm x 165mm x 3mm | 280fg01-165s |
| wg-280 filter glass, 25mm diameter | 280fg01-25 |
| wg-280 filter glass, 50mm diameter | 280fg01-50 |
| wg-280 filter glass, 50mm x 50mm x 3mm | 280fg01-50s |
| wg-295 filter glass, 165mm x 165mm x 3mm | 295fg01-165s |
| wg-295 filter glass, 25mm diameter | 295fg01-25 |
| wg-295 filter glass, 50mm diameter | 295fg01-50 |
| wg-295 filter glass, 50mm x 50mm x 3mm | 295fg01-50s |
| wg-305 filter glass, 25mm diameter | 305fg01-25 |
| wg-305 filter glass, 50mm diameter | 305fg01-50 |
| wg-305 filter glass, 50mm x 50mm x 3mm | 305fg01-50s |
| wg-320 filter glass, 25mm diameter | 320fg01-25 |
| wg-320 filter glass, 50mm diameter | 320fg01-50 |
| wg-320 filter glass, 50mm x 50mm x 3mm | 320fg01-50s |
| gg-395 filter glass, 165mm x 165mm x 3mm | 395fg03-165s |
| gg-395 filter glass, 25mm diameter | 395fg03-25 |
| gg-395 filter glass, 50mm diameter | 395fg03-50 |
| gg-395 filter glass, 50mm x 50mm x 3mm | 395fg03-50s |
| gg-400 filter glass, 165mm x 165mm x 3mm | 400fg03-165s |
| gg-400 filter glass, 25mm diameter | 400fg03-25 |
| gg-400 filter glass, 50mm diameter | 400fg03-50 |
| gg-400 filter glass, 50mm x 50mm x 3mm | 400fg03-50s |
| gg-420 filter glass, 165mm x 165mm x 3mm | 420fg03-165s |
| gg-420 filter glass, 25mm diameter | 420fg03-25 |
| gg-420 filter glass, 50mm diameter | 420fg03-50 |
| gg-420 filter glass, 50mm x 50mm x 3mm | 420fg03-50s |
| gg-435 filter glass, 165mm x 165mm x 3mm | 435fg03-165s |
| gg-435 filter glass, 25mm diameter | 435fg03-25 |
| gg-435 filter glass, 50mm diameter | 435fg03-50 |
| gg-435 filter glass, 50mm x 50mm x 3mm | 435fg03-50s |
| gg-455 filter glass, 165mm x 165mm x 3mm | 455fg03-165s |
| gg-455 filter glass, 25mm diameter | 455fg03-25 |
| gg-455 filter glass, 50mm diameter | 455fg03-50 |
| gg-455 filter glass, 50mm x 50mm x 3mm | 455fg03-50s |
| gg-475 filter glass, 165mm x 165mm x 3mm | 475fg03-165s |
| gg-475 filter glass, 25mm diameter | 475fg03-25 |
| gg-475 filter glass, 50mm diameter | 475fg03-50 |
| gg-475 filter glass, 50mm x 50mm x 3mm | 475fg03-50s |
| gg-495 filter glass, 165mm x 165mm x 3mm | 495fg03-165s |
| gg-495 filter glass, 25mm diameter | 495fg03-25 |
| gg-495 filter glass, 50mm diameter | 495fg03-50 |
| gg-495 filter glass, 50mm x 50mm x 3mm | 495fg03-50s |
| og-515 filter glass, 165mm x 165mm x 3mm | 515fg05-165s |
| og-515 filter glass, 25mm diameter | 515fg05-25 |
| og-515 filter glass, 50mm diameter | 515fg05-50 |
| og-515 filter glass, 50mm x 50mm x 3mm | 515fg05-50s |
| og-530 filter glass, 165mm x 165mm x 3mm | 530fg05-165s |
| og-530 filter glass, 25mm diameter | 530fg05-25 |
| og-530 filter glass, 50mm diameter | 530fg05-50 |
| og-530 filter glass, 50mm x 50mm x 3mm | 530fg05-50s |
| og-550 filter glass, 165mm x 165mm x 3mm | 550fg05-165s |
| og-550 filter glass, 25mm diameter | 550fg05-25 |
| og-550 filter glass, 50mm diameter | 550fg05-50 |
| og-550 filter glass, 50mm x 50mm x 3mm | 550fg05-50s |
| og-570 filter glass, 165mm x 165mm x 3mm | 570fg05-165s |
| og-570 filter glass, 25mm diameter | 570fg05-25 |
| og-570 filter glass, 50mm diameter | 570fg05-50 |
| og-570 filter glass, 50mm x 50mm x 3mm | 570fg05-50s |
| og-590 filter glass, 165mm x 165mm x 3mm | 590fg05-165s |
| og-590 filter glass, 25mm diameter | 590fg05-25 |
| og-590 filter glass, 50mm diameter | 590fg05-50 |
| og-590 filter glass, 50mm x 50mm x 3mm | 590fg05-50s |
| rg-610 filter glass, 165mm x 165mm x 3mm | 610fg07-165s |
| rg-610 filter glass, 25mm diameter | 610fg07-25 |
| rg-610 filter glass, 50mm diameter | 610fg07-50 |
| rg-610 filter glass, 50mm x 50mm x 3mm | 610fg07-50s |
| rg-630 filter glass, 165mm x 165mm x 3mm | 630fg07-165s |
| rg-630 filter glass, 25mm diameter | 630fg07-25 |
| rg-630 filter glass, 50mm diameter | 630fg07-50 |
| rg-630 filter glass, 50mm x 50mm x 3mm | 630fg07-50s |
| rg-645 filter glass, 165mm x 165mm x 3mm | 645fg07-165s |
| rg-645 filter glass, 25mm diameter | 645fg07-25 |
| rg-645 filter glass, 50mm diameter | 645fg07-50 |
| rg-645 filter glass, 50mm x 50mm x 3mm | 645fg07-50s |
| rg-665 filter glass, 165mm x 165mm x 3mm | 665fg07-165s |
| rg-665 filter glass, 25mm diameter | 665fg07-25 |
| rg-665 filter glass, 50mm diameter | 665fg07-50 |
| rg-665 filter glass, 50mm x 50mm x 3mm | 665fg07-50s |
| rg-695 filter glass, 165mm x 165mm x 3mm | 695fg07-165s |
| rg-695 filter glass, 25mm diameter | 695fg07-25 |
| rg-695 filter glass, 50mm diameter | 695fg07-50 |
| rg-695 filter glass, 50mm x 50mm x 3mm | 695fg07-50s |
| rg-715 filter glass, 165mm x 165mm x 3mm | 715fg07-165s |
| rg-715 filter glass, 25mm diameter | 715fg07-25 |
| rg-715 filter glass, 50mm diameter | 715fg07-50 |
| rg-715 filter glass, 50mm x 50mm x 3mm | 715fg07-50s |
| rg-780 filter glass, 165mm x 165mm x 3mm | 780fg07-165s |
| rg-780 filter glass, 25mm diameter | 780fg07-25 |
| rg-780 filter glass, 50mm diameter | 780fg07-50 |
| rg-780 filter glass, 50mm x 50mm x 3mm | 780fg07-50s |
| rg-830 filter glass, 165mm x 165mm x 3mm | 830fg07-165s |
| rg-830 filter glass, 25mm diameter | 830fg07-25 |
| rg-830 filter glass, 50mm diameter | 830fg07-50 |
| rg-830 filter glass, 50mm x 50mm x 3mm | 830fg07-50s |
| rg-850 filter glass, 165mm x 165mm x 3mm | 850fg07-165s |
| rg-850 filter glass, 25mm diameter | 850fg07-25 |
| rg-850 filter glass, 50mm diameter | 850fg07-50 |
| rg-850 filter glass, 50mm x 50mm x 3mm | 850fg07-50s |
